3-12m single and double Bent arm galvanized light pole

Short Description:

  • Hot dip galvanized street light pole,Resistance level>160km/H,20years lifespan:
  • Product Detail


    This single and double arm conical aluminium light columns are made from the raw Q235/Q345 steel, it is 6meters to 12meters(20ft to 40ft) high with a wall thickness of 3.0mm to 6.0mm(0.12inches to 0.19inches),Variable arm length from 1.2meter to 1.8meter(100inches to 150inches) with double arm type .The double lamp arms are designed to  mount the street lights. This seamless light pole has a simple and basic design,easy to install and maintain, high strength and time-tested.Generally it is applicable to street, square, stadium, highway , expressway,seaside etc. The lighting poles meet all applicable material ASTM standards,All welders have over 20 years welding experience.

    3M ~ 12M Street Light Pole Specification

    Light Pole Height Top Diameter Bottom Diameter Pole Thickness Base Plate
    3M 60 mm 130 mm 2.75 mm 250 * 250 * S14 mm
    4M 60 mm 130 mm 2.75 mm 260 * 260 * S14 mm
    5M 60 mm 140 mm 3.00 mm 260 * 260 * S14 mm
    6M 60 mm 145 mm 3.00 mm 300 * 300 * S16 mm
    7M 76 mm 160 mm 3.00 mm 300 * 300 * S16 mm
    8M 80 mm 180 mm 3.25 ~ 4.00 mm 320 * 320 * S20 mm
    9M 80 mm 180 mm 3.25 ~ 4.00 mm 350 * 350 * S20 mm
    10M 90 mm 200 mm 3.5 ~ 4.00 mm 400 * 400 * S20 mm
    11M 100 mm 205 mm 3.75 ~ 4.00 mm 400 * 400 * S20 mm
    12M 100 mm 220 mm 4.00 ~ 5.00 mm 400 * 400 * S20 mm

    Product Description

    street light pole lamp pole (2) street light pole lamp pole (1)

    street light pole lamp pole (3)

    street light pole lamp pole (4)

    street light pole lamp pole (7)


    详情页_12 详情页_13

    Yangzhou Lecuso New Energy Co.,Ltd.Estalished in 2005,an SO9001,CE,ROHS,TUV,IEC.cCC approved manufacturer and exporter of solar street light,Led street lightstreet light polesolar panel,solar sytem. Our company have experienced R&D engineers and we support OEM and ODM service
    In the past 15 years Lecuso has developed series of products
    Relating to solar power and led lighting based on market demand
    Lecuso has successfully completed houndreds of mega goverment proj ectsAnd have won clients’ uniform praise
    Our company welcome customers from all of the world,To establish and develop business contacts

    Our Certificate


    Project Show

    street light pole lamp pole (8) street light pole lamp pole (9) street light pole lamp pole (10) street light pole lamp pole (11)


    street light pole lamp pole (12)

    Contact us:

    If you are interested in any of our products, please contact us in time, I believe we can cooperate happily.





    Thank you for taking a long time to read our products, I hope your career will be more and more smooth!

  • Previous:
  • Next:

  • Q1. MOQ and delivery time ?
    A: NO MOQ required, sample testing welcome.. Mixed samples are acceptable.
    Sample needs 3-5 days, mass production time needs 1-2 weeks for order quantity more than
    Q2. What about the lead time?
    A: Firstly,let us know your requirements or application.
    Secondly,We quote according to your requirements or our suggestions.
    Thirdly,customer confirms the samples and places deposit for formal order.
    Fourthly,We arrange the production.
    Q3. Can you do OEM?
    A: Yes, we are 18 years factory,we have design team, engineer team, after-service team QC team etc.
    Q4. How about the shipping method ?
    A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.
    Q5. Do you offer guarantee for the products?
    A: Yes, we offer 2-5 years warranty to our products.
    Q6. How to deal with the faulty?
    A: Firstly, Our products are produced in strict quality control system
    Secondly, during the guarantee period, we will send new lights with new order for small quantity. For defective batch products, we
    will repair them and resend them to you or we can discuss the solution including re-call according to realsituation.
